Deviate Claymore Factory Mountain Bike

Claymore Factory MX Bike

AMP06-C5-001

Regular price€8.359,95
/
Tax & duties included on orders under €150, excluded on orders over €150.
Shipping calculated at checkout.

Size
Colour

We've picked up that you're in Italy. Sorry, we don't currently ship bikes to Italy.

Sale price bikes bought though Cycle To Work schemes will have a handling fee added.

This information is intended as a guide only.

Cycle To Work is a Government Initiative to encourage cycling to work. The idea is that by cycling to work, you get fitter and healthier, and at the same time reduce congestion and improve air quality.

In simplest terms, your employer pays for the bike, and you hire it from them through salary deductions. At the end of the hire period, the employer can sell you the bike. (Until the bike is paid for, you hire it from your employer, so don't get fired).

Your employer might administer the scheme themselves, or use a third party like one of the following:

GoGeta
Vivup
Green Commute Initiative
Cycle Solutions
My Benefits World
Cyclescheme

If your employer doesn't offer Cycle To Work as a benefit, you can send them this employer information from the Government that outlines how it all works.

For more information, click here to contact us or call 01330 828562.

We offer free UK delivery on all bikes unless bought through a Ride To Work Scheme.

We don't currently deliver complete bikes outside the UK.

Custom-built bikes can be delivered in kit form (for you to assemble) - we can include shipping to your country in your quote.

This site is protected by hCaptcha and the hCaptcha Privacy Policy and Terms of Service apply.

Pedals

Sale price bikes bought though Cycle To Work schemes will have a handling fee added.

This information is intended as a guide only.

Cycle To Work is a Government Initiative to encourage cycling to work. The idea is that by cycling to work, you get fitter and healthier, and at the same time reduce congestion and improve air quality.

In simplest terms, your employer pays for the bike, and you hire it from them through salary deductions. At the end of the hire period, the employer can sell you the bike. (Until the bike is paid for, you hire it from your employer, so don't get fired).

Your employer might administer the scheme themselves, or use a third party like one of the following:

GoGeta
Vivup
Green Commute Initiative
Cycle Solutions
My Benefits World
Cyclescheme

If your employer doesn't offer Cycle To Work as a benefit, you can send them this employer information from the Government that outlines how it all works.

For more information, click here to contact us or call 01330 828562.


Sorry, we can't ship this item to Italy.

The new Deviate complete Factory spec bikes are built to a “money no object” spec at a price we're pretty excited about. No one else is offering a bike to this spec for less than £10k. On top of that, the Claymore and Highlander 2 are awesome bikes; being early adopters of high pivots, Deviate really know what they are doing with the platform.

The spec of the Claymore Factory is loaded with highlights, including the new Shimano Di2 electronic XT/XTR drivetrain and the latest XTR 4 piston brakes. There's no need to junk the stock handlebar and post for an upgrade, OneUp Carbon V2 bars and a V2 dropper in a sensible size drop are fitted and there's even a OneUp EDC Lite tool built into the steerer.

The Factory spec is named after the Fox Factory suspension, with this bike running the new Float X2 shock and 36 Factory fork with Glidecore air spring.

  • Lifetime bearing replacement programme.
  • Lifetime warranty (for first owner).
  • Crash replacement policy.
  • Linkage bearing grease ports.

Specification

Frame Carbon Fibre, High Pivot with 18t Idler, Grease Ports on Pivot & Idler Bearings, Bolt on Rubber Downtube Protection, Moulded Chainstay Protector, Recessed Top Tube Brake Hose and Mech Cable Routing, Internal Dropper Cable Routing, Accessory Mounts, 165 mm Travel, 34.9 mm Seatpost, 148x12mm Boost Rear Axle, 180 mm Post Mount Brake Mount, 73 mm Threaded BSA BB
Front Suspension Fox 38 Float Factory Series, Kashima, GRIP X2 Damper, Adjustable HSC - LSC - HSR - LSR, 170mm Travel, 44 mm Offset, 29", 110x15 mm Boost Axle
Rear Suspension Fox Float X2 Factory, 2 Position Open/Firm Lever, Adjustable HSC - LSC - HSR - LSR, 230x60, 165 mm Travel
Front Wheel 29", Hub: OneUp Front Hub, 110x15 mm Boost, 6 Bolt
Rim: Reserve 30 HD AL 6069, 30mm Internal Width, 32H
Rear Wheel 27.5, Hub: OneUp Rear Hub44T Engagement, 148x12mm Boost, 6 Bolt
Rim: Reserve 30 HD AL 6069, 30mm Internal Width, 32H
Front Tyre Continental Kryptotal Front Tyre, Enduro Supersoft, 2.4", 29"
Rear Tyre Continental Kryptotal Rear Tyre, Downhill, Soft, 2.4", 27.5
Derailleur Shimano XTR M9250 Di2 Electronic
Shift Lever Shimano XT Di2 SW-M8250, 12 Speed
Crankset Shimano FC-M8200 XT Enduro, 55mm Chainline , 32T Chainring
Chain Shimano XTR M9100, 12 Speed
Cassette Shimano XT CS-M8200, 10-51T, 12 Speed
Front Brake Shimano XTR M9220, 4 Piston
Front Brake Rotor Galfer Shark Brake Disc, 203 mm, 6 Bolt
Rear Brake Shimano XTR M9220, 4 Piston
Rear Brake Rotor Galfer Shark Brake Disc, 203 mm, 6 Bolt
Handlebar OneUp Components Carbon V2
Stem OneUp Components Forged
Grips Peaty's Monarch Mushroom Grips
Headset Cane Creek Hellbender 70
Seatpost OneUp Dropper Post V2
Saddle SDG Bel-Air 3 Lux-Alloy
Pedals
Extras
Weight

Geometry & Sizing

20Twenty Bike Sizing Chart
Deviate Claymore MX/29"
Dimensions using a Fox 38 170mm Fork
Sizes in mm M L XL
A: Stack 620 630 640
B: Reach 460 490 520
C: Head Tube
Angle
64.3°
D: Head Tube
Length
92 108 114
E:
Seat Tube Angle
78°
F: Seat Tube
Length
410 430 450
G: Effective
Top Tube
592 622 656
H: BB Height
I: BB Drop 12/30
J: Chainstay Length 435/441
K: Wheelbase 1228/1233 1263/1268 1298/1303
L: Standover
M: Fork Offset 44
Seatpost Diameter 34.9
Size Rider Height
M 170 cm - 180 cm
L 177 cm - 189 cm
XL 186 cm - 198 cm
