Amazing spec across the range of price points and some unique features on the MY25 models make the Alpine Trail range out as some of the best value and most cutting edge enduro bikes on the market.
We have some incredible deals on the carbon models. When these were launched they were way ahead in terms of geo, so they are by no means out of date, and the spec sheets are fantastic. The C2 includes a 38 Performance Elite fork with the fully adjustable damper.
All new alloy MY25 models are also very well specced at every price point and the range of adjustments is mind-boggling! Flip chip adjustable chainstay lengths and easily adjustable headset cups let you really make the bike your own. When you've finally run out of new combos to try, we can sell you a 29" rear wheel, and you can start again...
Marin Alpine Trail Geometry & Sizing
Alpine Trail Alloy 2024 29"/27.5 Wheels - 0° Headset Cup - High BB/Short CS |
||||
---|---|---|---|---|
Sizes in MM | S | M | L | XL |
A: Stack | 620.08 | 633.51 | 642.6 | 646.93 |
B: Reach | 430 | 460 | 490 | 520 |
C: Head Tube Angle |
63.5° | |||
D: Head Tube Length |
100 | 110 | 125 | 130 |
E: Effective Seat Tube Angle |
79.2° | 79° | 78.8° | 78.6° |
F: Seat Tube Length |
400 | 420 | 430 | 460 |
G: Effective Top Tube |
556 | 592 | 626 | 659 |
H: BB Height | 352 | |||
I: BB Drop | 32 | |||
J: Chainstay Length | 435 | |||
K: Wheelbase | 1211.42 | 1248.11 | 1282.57 | 1317.8 |
L: Standover | 698.32 | 689.88 | 695.6 | 698.13 |
M: Fork Offset | 44 | |||
Seatpost Diameter | 34.9 | |||
Seatpost Drop | 150 | 170 | 170 | 200 |
Handlebar Width | 780 | |||
Stem Length | 35 | |||
Crank Length | 160 |
Size | Rider Height |
---|---|
S | 160 cm - 168 cm |
M | 165 cm - 178 cm |
L | 178 cm - 185 cm |
XL | 185 cm - 193 cm |
