Confidence inspiring no matter what the terrain, the new Deviate Claymore has had nothing but praise from everyone who has ridden it. It's long, low and slack without being too long, low and slack, so while it's been designed to descend fast, it's not a complete liability on the climbs or pedally bits of trail. Like the Highlander, the bike is well-mannered, with almost no pedal bob when you are on the pedals.

  • 165 mm of high pivot travel.
  • 18t idler with twin outboard bearings.
  • Twin lip wiper seals throughout.
  • Grease ports fitted to all pivot and idler bearings.
  • Cable gutter - clean lines with easy installation.
  • Standard 126 link chain.
  • 2.6" tyre clearance - Threaded BB - Boost axle - water bottle compatible

Deviate Claymore Geometry & Sizing

Claymore with 170 mm Travel / 44 mm off set Fox 38
Sizes in mm
Size M L XL
A: Stack 620 630 640
B: Reach 460 490 520
C: Head Tube
Angle
64.3° 64.3° 64.3°
D: Head Tube
Length
92 108 114
E: Seat Tube
Angle
78° 78° 78°
F: Seat Tube
Length
410 430 450
G: Effective
Top Tube
592 622 656
H: BB Height
I: BB Drop 30 30 30
J: Chainstay Length 441 441 441
K: Wheelbase 1233 1268 1303
L: Standover
M: Fork Offset 44 44 44
Seatpost Diameter 34.9 34.9 34.9




Size Rider Height
M 170 cm - 180 cm
L 170 cm - 189 cm
XL 186 cm - 198 cm
