All new and bang up to date with the most comprehensive feature list of any mountain bike on the market, there's a Gen 7 Fuel for pretty much every one.

Features in common across all models:

  • Adjustable suspension leverage rates.
  • Modern geometry with taller stack height compared to Gen 6 Fuel.
  • Size specific chain stay.
  • Internal frame storage.
  • Straight seat tubes for maximum dropper post insertion.
  • ZS headset cup can be replaced with angle adjust headsets (Treks' own available here).
  • Chainstay and downtube protection.

Three varieties of Fuel are available, all using basically the same frame but with different rocker linkages and suspension. If you decide you want to change your bike to one of the other version later down the line, it's a case of changing the suspension and linkage.

  • EX: 29" wheels,150/145mm travel (Size S has mixed wheel sizes)
  • LX: 29" Wheels, 170/160mm travel
  • MX: Mixed Wheels, 16/150mm travel


Trek Fuel Geometry & Sizing

Trek Fuel EX/MX/LX Gen 7 Geometry
Size Small EX runs mixed wheel sizes
Sizes in mm S M L XL XXL
A: Stack 610/613/619 624/627/633 638/641/647 651/654/661 665/668/674
B: Reach 431/426/418 460/456/448 485/482/473 510/507/498 530/527/518
C: Head Tube
Angle
64.5°/64.2°/63.4° 64.5°/64.2°/63.4° 64.5°/64.2°/63.4° 64.5°/64.2°/63.5° 64.5°/64.2°/63.5°
D: Head Tube
Length
95 110 125 140 155
E: Effective
Seat Tube Angle
78.7°/78.3°/77.5° 78.3°/77.5°/77.2° 77.4°/77.0°/76.4° 76.9°/76.6°/75.9° 76.4°/76.1°/75.4°
F: Seat Tube
Length
370 400 420 455 475
G: Effective
Top Tube
548/549/552 583/584/586 617/618/621 651/652/655 680/682/684
H: BB Height 340/343/347 339/343/346 339/343/346 339/343/346 339/343/346
I: BB Drop 34/31/26 35/31/27 35/31/27 35/31/27 35/31/27
J: Chainstay Length 437 437 442 447 452
K: Wheelbase 1187/1191/1200 1225/1228/1237 1262/1264/1273 1298/1301/1310 1330/1332/13410
L: Standover 741/745/750 742/747/752 749/754/759 755/760/765 764/769/773
M: Fork Offset 44
Seatpost Diameter 34.9

Size Rider Height
S 155cm-165cm 5'1"-5'5"
M 165cm-177cm 5'5"-5'10"
L 177cm-188cm 5'10"-6'2"
XL 188cm-195cm 6'2"-6'5"
XXL 195cm-203cm 6'5"-6'8"
