One of the most iconic names in mountain biking is back with a bang! The all-new Bottlerocket is a 27.5 specific bike suitable for park and freeride. Two completes and a frame are available; a 200mm pure park build with a triple crown fork, or a more pedallable 180mm version with a dropper post and single crown fork.

Transition Bottlerocket Adjustable Chainstays

Standard chainstay length can be increased by 5 or 10mm length thanks to the replaceable SALSA chainstay length adjusters.

Transition Bottlerocket CHIPS

CHIPS Shock progression and geometry adjustment can alter the bikes head angle and progression independently.

Transition Bottlerocket Gravity Cast Bottom Bracket

Gravity Cast BB area, adding strength to the BB and main pivot area and precise shock mount alignment for the new CHIPS shock pivot.

Transition Bottlerocket Forged Rocker

Further strength with a forged rocker and seat stays keep the back of the bike in line through sketchy landings.

Dual crown builds run a Marzocchi Bomber 58 with huge 40mm stanchions and SRAM GX DH drivetrain components. Single crown Bottlerockets use a Marzocchi Bomber Z for with 38mm stanchions and a dropper post. Both builds have Maven brakes and all models run a Marzocchi Bomber Air shock.

Bottlerocket Geometry & Sizing

Transition Bottle Rocket Geometry
High/Low
Sizes in mm S M L XL
A: Stack 607/610 616/619 625/628 625/628
B: Reach 425/421 450/446 475/471 500/496
C: Head Tube
Angle
64°/63.6°
D: Head Tube
Length
100 110 120 120
E: Effective
Seat Tube Angle
79.4/79.0° 78.7°/78.4° 78.2°/77.8° 77.7°/77.3°
F: Seat Tube
Length
360 390 420 440
G: Effective
Top Tube
538 573 606 638
H: BB Height 340/335
I: BB Drop 15/20
J: Chainstay Length 436
K: Wheelbase 1191 1220 1249 1279
L: Standover
M: Fork Offset 38
Seatpost Diameter 31.6
Seatpost Drop 150 170 200 230
Stem Reach 35
Handlebar Width x Rise 780x20 780x30 800x30
Crank Length 165

Transition Size Guide
