The Alcatraz family of dirt jump bikes are all based on Marin Series 3 aluminium tube sets, with short chain stays and ambidextrous internal cable routing. Effectively available in three sizes with the addition of the Alcatraz Jr 24" wheeled bike, specs include a rigid forked bike offering amazing value for money and a Manitou Circus suspension fork equipped bike for a ready-to-roll bike suitable for all sorts of terrain.
Alcatraz Geometry & Sizing
| Marin Alcatraz Geometry | |||
|---|---|---|---|
| Sizes in mm | Jr | Regular | Long |
| A: Stack | 525 | 575 | 580 |
| B: Reach | 360 | 385 | 430 |
| C: Head Tube Angle |
69.0° | ||
| D: Head Tube Length |
112 | 115 | 120 |
| E: Effective Seat Tube Angle |
69° | ||
| F: Seat Tube Length |
320 | ||
| G: Effective Top Tube |
600 | 646 | |
| H: BB Height | 317 | ||
| I: BB Drop | 8 | 22 | |
| J: Chainstay Length | 369 | 395 | |
| K: Wheelbase | 1037 | 1083 | |
| L: Standover | 370 | 400 | |
| M: Fork Offset | |||
| Seatpost Diameter | 30.9 | ||
| Stem Length | 35 | 40 | |
| Handlebar Width | 700 | 750 | 750 |
| Crank Length | 152 | 170 | |
