Name: Alpine Trail E2 eBike
Brand: Marin
SKU: 739063001
Price: 5699.0 GBP
Availability: InStock

Marin Alpine Trail E2 eMTB Brown Cockpit

£5,699.00

Tax included. Shipping calculated at checkout.

We offer free UK delivery on all bikes & ebikes except Trek, unless bought through a Ride To Work Scheme.

We don't deliver complete bikes or ebikes outside the UK.

Trek Bikes

Over £1000: Free Scottish Mainland Delivery
Under £1000: £50 Scottish Mainland Delivery

Pedals

[{"id":58255669854592,"title":"S \/ Brown","option1":"S","option2":"Brown","option3":null,"sku":"739063001","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Alpine Trail E2 eBike - S \/ Brown","public_title":"S \/ Brown","options":["S","Brown"],"price":569900,"weight":30000,"compare_at_price":null,"inventory_management":"shopify","barcode":"739063001","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[],"price":569900,"compare_at_price":null,"per_delivery_price":569900,"selling_plan_id":738745024896,"selling_plan_group_id":"78bf5001497bf8c6dd02fd95183bb958d0fe178e"}],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":58255057551744,"title":"M \/ Brown","option1":"M","option2":"Brown","option3":null,"sku":"739063002","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Alpine Trail E2 eBike - M \/ Brown","public_title":"M \/ Brown","options":["M","Brown"],"price":569900,"weight":30000,"compare_at_price":null,"inventory_management":"shopify","barcode":"739063002","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[],"price":569900,"compare_at_price":null,"per_delivery_price":569900,"selling_plan_id":738745024896,"selling_plan_group_id":"78bf5001497bf8c6dd02fd95183bb958d0fe178e"}],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":58255057584512,"title":"L \/ Brown","option1":"L","option2":"Brown","option3":null,"sku":"739063003","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Alpine Trail E2 eBike - L \/ Brown","public_title":"L \/ Brown","options":["L","Brown"],"price":569900,"weight":30000,"compare_at_price":null,"inventory_management":"shopify","barcode":"739063003","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[],"price":569900,"compare_at_price":null,"per_delivery_price":569900,"selling_plan_id":738745024896,"selling_plan_group_id":"78bf5001497bf8c6dd02fd95183bb958d0fe178e"}],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":58255057617280,"title":"XL \/ Brown","option1":"XL","option2":"Brown","option3":null,"sku":"739063004","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Alpine Trail E2 eBike - XL \/ Brown","public_title":"XL \/ Brown","options":["XL","Brown"],"price":569900,"weight":30000,"compare_at_price":null,"inventory_management":"shopify","barcode":"739063004","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[],"price":569900,"compare_at_price":null,"per_delivery_price":569900,"selling_plan_id":738745024896,"selling_plan_group_id":"78bf5001497bf8c6dd02fd95183bb958d0fe178e"}],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Sale price bikes bought though Cycle To Work schemes will have a handling fee added.

This information is intended as a guide only.

Cycle To Work is a Government Initiative to encourage cycling to work. The idea is that by cycling to work, you get fitter and healthier, and at the same time reduce congestion and improve air quality.

In simplest terms, your employer pays for the bike, and you hire it from them through salary deductions. At the end of the hire period, the employer can sell you the bike. (Until the bike is paid for, you hire it from your employer, so don't get fired).

Your employer might administer the scheme themselves, or use a third party like one of the following:

GoGeta
Vivup
Green Commute Initiative
Cycle Solutions
My Benefits World
Cyclescheme

If your employer doesn't offer Cycle To Work as a benefit, you can send them this employer information from the Government that outlines how it all works.

For more information, click here to contact us or call 01330 828562.

A ground up redesign sees the Bosch powered Alpine Trail E lose 3kg, while retaining its adjustability and 800wh battery.

The full Alpine Trail E range is supplied with a 27.5 rear wheel, but the geo can be altered to suit 29" wheels front and back. Other than a wheel, no additional parts are required, just use the built-in flip chips, which have laser etched numbers to show their settings.

Useful upgrades over the E1 include the new Zeb Select+ fork with LinearXL airspring and a 12 speed drivetrain.

Specification

Frame	Series 4 6061 Aluminum, Adjustable Chainstay Length, Adjustable Headtube Angle, Integrated Battery/Charging Port, Built-In Speed Sensor, MultiTrac Suspension Platform, Moulded Chainstay Protector, 160 mm Travel, 34.9 mm Seatpost, 148x12mm Boost Rear Axle, 180mm Post Mount Brake Mount
Front Suspension	Fox 38 Float Performance Elite Series, GRIP2 Damper, Adjustable HSC - LSC - HSR - LSR, 170mm Travel, 44 mm Offset, 29", 110x15 mm Boost Axle
Motor	Bosch Performance Line CX (120nm)
Battery	Bosch PowerTube 800Wh
Switch	Bosch BRC3300 Bluetooth Remote 22.2mm Clamp
Display	Bosch Kiox 400C, Dynamic Colour Display, USB-C Charging Port
Rear Suspension	ROCKSHOX Vivid Select+, 2 Position Open/Firm Lever, TouchDown RCT Damper with Adjustable Hydraulic Bottom Out, Adjustable Compression and Rebound Damping, DebonAir, 205x65 Trunnion, 160 mm Travel
Front Wheel	29", WTB Sportterra Tough i30, 30mm Internal Width, 110x15 mm Boost, Centrelock
Rear Wheel	27.5, 148x12mm Boost, Centrelock
Front Tyre	Schwalbe Magic Mary Gravity Pro Radial Super Gravity, Ultra Soft, 2.4", 29"
Rear Tyre	Schwalbe Magic Mary Gravity Pro Radial 2.5" Soft, 27.5
Derailleur	SRAM Eagle 70 Transmission, 12 Speed
Shift Lever	SRAM Eagle 90 Single Click, 12 Speed

Crankset	Marin Forged Alloy, 34T Chainring
Chain	SRAM Eagle 70 , 12 Speed
Cassette	SRAM S1000 CS1270 T-Type, 10-52T, 12 Speed
Front Brake	SRAM Maven Bronze, 4 Piston
Front Brake Rotor	SRAM HSC, 203 mm, Centrelock
Rear Brake	SRAM Maven Bronze, 4 Piston
Rear Brake Rotor	SRAM HSC, 200 mm, Centrelock
Handlebar	Marin Trail Bar, 7000 Alloy, 35 mm Diameter, 20mm Rise, 5º Up, 8º Back
Stem	Marin CNC
Grips	Marin Grizzly Lock On
Headset	FSA Custom, Adjustable
Seatpost	X-Fusion Manic
Saddle	Marin Short Nose
Pedals
Charger	Bosch EB12.110.016; 2A
Extras	Cush Core Pro Tire Inserts, Marin Tire Sealant 300ml Bottle
Weight

Geometry & Sizing

Measurement (MM)	S	M	L	XL
Marin Alpine Trail E2 Geometry
A: Stack	620	634	643	647
B: Reach	430	460	490	520
C: Head Tube Angle	63.5°	63.5°	63.5°	63.5°
D: Head Tube Length	110	115	125	130
E: Effective Seat Tube Angle	79°	79°	79°	79°
F: Seat Tube Length	400	420	430	450
G: Effective Top Tube	556	592	626	659
H: BB Height	352	352	352	352
I: BB Drop	24/7	24/7	24/7	24/7
J: Chainstay Length	442	442	442	442
K: Wheelbase	1211	1248	1283	1318
L: Standover	683	690	695	698
M: Fork Offset	44	44	44	44
Seatpost Drop	150	170	200	200
Stem Length	35	35	35	35
Handlebar Size	800x20	800x20	800x20	800x20
Crank Length	150	150	150	150

Bike Size	S	M	L	XL
Marin Alpine Trail E Size Guide
Rider Height	157-168cm 5'2"-5'6"	168-175cm 5'6"-5'9"	175-185cm 5'9"-6'1"	185-193cm 6'1"-6'4"
